Sensor

1/1.7” 8.0M Pixel SONY IMX226

Minimum illumination

0.005Lux@F1.2

Wide Dynamic

≥80dB

Signal to Noise Ratio

≥50dB（AGC OFF）

Gain Control

Auto/Manual

White Balance

Automatic, indoor, outdoor, sodium lamp mode, manual

Digital Noise Reduction

Support DNR, 3DNR

Exposure mode

Program mode, shutter mode (customizable shutter interval, license plate capture), manual

Electronic shutter

1/2 - 1/20,000s，Support slow shutter speed

Privacy Protection

Support 3D privacy area on/off (4 privacy areas can be set on the same screen)

Day&Night

Automatic ICR filter color to black, fixed black and white, fixed color, external control

focal length

6mm -192mm

Optical Zoom

32x

Aperture Value

F1.5~F5.0

Viewing Angle

61.2°（Near）/ 2.3°（Far）

Preset

254

Automatic Mode

Support 4 automatic cruise control, 4 automatic track tracking, and 4 automatic line scanning

3D Positioning

Support clicking to center and selecting boxes to zoom in

Multi Stream

Support dual encoding and triple stream

Video Compression

H.265 Main Profile / H.264 Main profile / M-JPEG

Audio Compression

G711A/U，PCM，AAC

Maximum Resolution

3840×2160@30fps

Resolution

Main Stream：3840x2160、2592x1944、2592x1520、2304x1296、1920x1080、1280x960、1280×720

Sub Stream：640×480、480x360、352×288、320×240、176×144、Off

MJPEG：1920x1080、1280x720、Off

Output Bitrate

Fixed bit rate (CBR) or variable bit rate (VBR), the bit rate can be set within the range of 32Kbps~10Mbps

OSD

Support channel name, date and time overlay, with adjustable overlay position;

Number of visits

3 users for the main stream and 6 users for the sub stream

Network Protocol

TCP/IP，HTTP，NTP，IGMP，DHCP，UDP，SMTP，RTP，RTSP，ARP，DDNS，DNS，HTTPS，P2P

ONVIF

Standard ONVIF2.4

Network Interface

1 10/100BaseT Ethernet, RJ45 interface

Alarm Interface

1 input/1  output

Audio Interface

1 audio input, 1 audio output

Working Temperature

-40°C ~60°C

Working Humidity

0%-90% RH(No condensation)
